Marking equipment

High-precision integrated marking shoe, screeding type, standard configuration: 150mm

Grounded blade

Inlaid hard alloy, and also have pure alloyed grounded blade for your choice

Paint container capacity

100kg(4 bags thermoplastic paint)

Paint container

Double layer stainless steel, equipped with inserted dismountable manumotive stirring device, the container is removable & interchangeable for quick color changes

Glass beads container capacity

10kg

Glass beads container

Automatic spreader

Glass beads dispenser

100/150/200/250/300/400/450mm(optional)

Line thickness

1.0-3.0mm(adjustable)

Line marking width

50/100/150/200/250/300/400/450mm(optional)

Heating temperature

180~210ºC

Heating Mode

Liquefied petroleum gas heating

Gas tank

15kg

Machine Weight

126kg

Dimension

1150×850×950mm
